Ferrite magnetic block Ferrite magnet with 16mm length, 9mm width and 5mm thickness. The pulling force is n.d. Kg. Max temperature: 250 °C Axial magnetization
SM05.853 Threaded Hole Neodymium magnetic system with 8mm diameter, 5mm thickness and a 3mm threaded hole with M3 thread. It contains an N52 magnet. The pulling force is 1,20 Kg. Max temperature resistance: 80°C
SM08.1654 Threaded Rod Neodymium magnetic system with 16mm diameter, 5mm thickness and a 10mm threaded rod with M4 thread. It contains an N35 magnet with an additional waterproof resin coating. The pulling force is 3,00 Kg. Max temperature resistance: 60°C
SM08.2254 Threaded Rod Neodymium magnetic system with 22mm diameter, 5mm thickness and a 6mm threaded rod with M4 thread. It contains an N35 magnet with an additional waterproof resin coating. The pulling force is 8,00 Kg. Max temperature resistance: 60°C
SM08.2255 Threaded Rod Neodymium magnetic system with 22mm diameter, 5mm thickness and a 15mm threaded rod with M5 thread. It contains an N35 magnet with an additional waterproof resin coating. The pulling force is 6,00 Kg. Max temperature resistance: 60°C
SM09.1553 Straight Hole Neodymium magnetic system with 15mm diameter, 5mm thickness and a 3mm passing hole. It contains an N35 magnet. The pulling force is 4,00 Kg . Max temperature 80 °C
SM09.2253 Countersunk Threaded Hole Neodymium magnetic system with 22mm diameter, 5mm thickness and a M3 thread present on the smaller section of the hole It contains an N35 magnet. The pulling force is 13,00 Kg . Max temperature 80 °C
SM14.1550 Threaded Rod Neodymium magnetic system with 15mm diameter, 5mm thickness and a 12mm threaded rod with M4 thread. It contains an N35 magnet. The pulling force is 3,00 Kg. Max temperature resistance: 80°C
SM14.2254 Threaded Rod Neodymium magnetic system with 22mm diameter, 5mm thickness and a 6mm threaded rod with M4 thread. It contains an N40 magnet. The pulling force is 15,00 Kg. Max temperature resistance: 80°C
SM23.853 N42 Superpot Threaded Hole Neodymium magnetic system with 8mm diameter, 5mm thickness and a 2mm threaded hole with M3 thread. It contains an N42 magnet. The pulling force is 1,60 Kg. Max temperature resistance: 80°C
Ferrite magnetic block Ferrite magnet with 40mm length, 10mm width and 5mm thickness. The pulling force is n.d. Kg. Max temperature: 250 °C Axial magnetization
Ferrite magnetic block Ferrite magnet with 40mm length, 20mm width and 5mm thickness. "Marked North" variant with a dot indicating the north pole. The pulling force is 2,00 Kg. Max temperature: 250 °C Axial magnetization
Ferrite magnetic block Ferrite magnet with 50mm length, 20mm width and 5mm thickness. The pulling force is 1,10 Kg. Max temperature: 250 °C Axial magnetization
Neodymium magnetic block Neodymium magnet with 10 mm length, 10 mm width and 5 mm thickness. This magnet is N35 nickel coated with axial magnetization. The pulling force is 2,10 Kg . Max temperature 80° C
Neodymium magnetic block Neodymium magnet with 15 mm length, 10 mm width and 5 mm thickness. This magnet is N35 nickel coated with axial magnetization. The pulling force is 3,50 Kg . Max temperature 80° C
Neodymium magnetic block black Neodymium magnet with 20 mm length, 10 mm width and 5 mm thickness. This magnet is N35 black epoxy coated with axial magnetization. The pulling force is 4,90 Kg . Max temperature 80° C
Ferrite magnetic ring Ferrite magnet with 20mm outer diameter, 10mm inner diameter and 5mm thickness. The pulling force is n.d. Kg. Max temperature: 250 °C Axial magnetization
SM30.1605 Countersunk Hole Neodymium magnetic system with 16mm diameter, 5mm thickness and a 7,2/3,5mm passing countersunk hole. It contains an N35 magnet. The pulling force is 7,50 Kg. Max temperature resistance: 80°C
Ferrite magnetic ring Ferrite magnet with 25mm outer diameter, 12,5mm inner diameter and 5mm thickness. The pulling force is 0,60 Kg. Max temperature: 250 °C Axial magnetization
Neodymium magnetic disc Neodymium magnet with 3 mm diameter and 5 mm thickness. This magnet is N35 nickel coated with axial magnetization. The pulling force is 0,29 Kg . Max temperature 80° C
SM33.1605 Screw Socket Neodymium magnetic system with 16mm diameter, 5mm thickness and a 8mm threaded socket with M4 thread. It contains an N35 magnet. The pulling force is 8,30 Kg. Max temperature resistance: 80°C
Neodymium magnetic disc Neodymium magnet with 4 mm diameter and 5 mm thickness. This magnet is available in N35 and N48. Nickel coated with axial magnetization. Max temperature 80° C
Neodymium magnetic disc Neodymium magnet with 5 mm diameter and 5 mm thickness. This magnet is N35 nickel coated with axial magnetization. The pulling force is 0,73 Kg . Max temperature 80° C
Neodymium magnetic disc Neodymium magnet with 5 mm diameter and 5 mm thickness marked south. You will find a red dot that indicates the pole where is marked, in this case the magnet has the red dot on the south pole. This magnet is N35 nickel coated with axial magnetization. The pulling force is 0,73 Kg . Max temperature 80° C
Neodymium magnetic disc Neodymium magnet with 6 mm diameter and 5 mm thickness. This magnet is N35 nickel coated with axial magnetization. The pulling force is 1,00 Kg . Max temperature 80° C
